Welding cable and clamp shown sold separately. For welding clamp information consult factory

Coxreels’ large capacity hand crank welding reels are designed to increase safety, efficiency, and productivity while keeping work areas and vehicles clean and organized. Save money by neatly storing and prolonging the life of costly welding cable. Available in hand crank and power rewind.

ELECTRICAL COMPONENTS SECURED INSIDE THE DRUM	Electrical components secured inside the drum afford a compact, narrow width. The cover is easily removed for field servicing. For Electrode Lead or Work Lead applications. Each lead requires a separate reel. “Current Path” runs through a continuous 400 AMP-rated slip ring Long-handled lock pin prevents drum from turning when not in use Adjustable brake prevents backlash during payout Durable powder paint finish Coxreels’ quality heavy duty steel construction
CAUTION: When using for extended periods of time, unwind all cable from reel to prevent heat build-up. CABLE TYPE & CAPACITY  MODEL WEIGHT HEIGHT WIDTH DEPTH #2 #1 #1/0 #2/0 (Less Cable) (lbs.) -- (w/handle) -- 300ft. 250ft. 200ft. 150ft. 1125WCL-6-C 31 18-1/8" 21-3/4” 17” 500ft. 500ft. 400ft. 300ft. 1125WCL-12-C 35 18-1/8" 27-3/4” 17”
1125 Stacking Bracket available for work and electrode lead combos (right). Consult factory
