COXREELS’ new POLY-PRO™ Hose Reels are designed to exceed the industry’s demand for a self-retracting polypropylene hose reel. They are standard-equipped with air or water hose to 50 feet, neatly wound and protected by a durable, U.V.-stabilized, polypropylene case. Lightweight, portable, and easy to handle, these hose reels weigh less than 17 lbs. including mounting bracket, easy carry handle, connector hose, hose and hose stop. POLY-PRO™ Reels are corrosion resistant, virtually maintenance free and designed to deliver continuous trouble-free performance.

“AIR HOSE”
Model No. A-A10-350

“EASY HOSE”
Model No. A-E10-450

“COLD WASH”
Model No. A-C10-450

“HOT WASH”
Model No. A-H10-450
FEATURES AND BENEFITS:
  • Lightweight/Compact Design
  • Easy Carry Handle for Portability
  • Detachable Mounting Bracket
  • Bracket Rotates 160 Degrees
  • Self-Retracting Spring Motor
  • Air and Water Hose to 50 Feet
  • Hose Locks at Desired Length
  • Adjustable Hose Stop
  • Impact Resistant Polypropylene Case
  • U.V. Stabilized
  • Corrosion Resistant
  • 3’ Inlet Connector Hose
  • Wall Mountable
  • Brass Swivel Inlet/Shaft
  • Virtually Maintenance Free

APPLICATIONS/MARKETS
General Industrial, Automotive Service & Repair, Paint & Body Shops, Agricultural, Farm & Ranch, Aircraft Servicing, Mining, Manufacturing and Assembly, Facility Maintenance, RV Industry, Fleet Maintenance, Mobile Service Units, Recreational Facilities, Domestic Home and Garden Care, and More.

ADDITIONAL BRACKET OPTIONAL (Model No. WAH217)
The Poly-Pro Series hose reels are designed to be portable. With additional mounting brackets, the reels can be easily transported and remounted in various selected locations.

  • Made of Durable Polypropylene
  • Fits All Models
  • Corrosion Resistant
  • Easily Secured with Standard Padlock

 POLY-PRO SERIES
Model #
Description
Hose Type
Length
PSI
ID
Swivel Inlet
Hose Inlet
Outlet
Color
Aprx Ship
Wt. (lbs.)
A-A10-350
Air Hose
PVC
50’
250
3/8”
3/8” NPT
1/4”NPT
1/4” NPT
Blue
18
A-E10-450
Easy Hose
PVC
50’
145
1/2”
3/8” NPT
Garden
Garden
Green
18
A-C10-450
Cold Wash
PVC
50’
145
1/2”
3/8” NPT
Garden
3/8” NPT
Blue/Black
18
A-H10-450
Hot Wash
HMW/PVC
50’
90
1/2”
3/8” NPT
1/4” NPT
1/4’ NPT
Blue/Red
19

 SIZE INDEX CHART
Model
 OVERALL REEL DIMENSIONS
 WIDTH HEIGHT LENGTH
All 20" 16-1/2" 8-7/8"
