EZ-P SERIES
Performance Safety Reel

LOW PRESSURE COXREELS - The standard hose is for air or water service only. The basic reel without hose can be used for air, water or oil. Maximum temperature 150o Fahrenheit.
HOSE* LESS HOSE
Model I.D. O.D. FT. SIZE
INDEX
(Chart)		 PSI APRX.
LBS.		 MODEL PSI APRX.
LBS.
EZ-P-LP-325 3/8” 21/32” 25 1 300 35 EZ-P-LPL-325
 300 28
EZ-P-LP-350 3/8” 21/32” 50 2 300 51 EZ-P-LPL-350 300 39
MEDIUM PRESSURE COXREELS - Reels are furnished standard with S.A.E. 100R1 AX thin cover one wire braid hose suitable for air, water or oil applications. Maximum temperature 250o F.
HOSE* LESS HOSE
Model I.D. O.D. FT. SIZE
INDEX
(Chart)		 PSI APRX.
LBS.		 MODEL PSI APRX.
LBS.
EZ-P-MP-425 1/2” 3/4” 25 3 2500 48 EZ-P-MPL-425 3000 40
HIGH PRESSURE COXREELS - Reels are furnished standard with S.A.E. 100R2 FX thin cover two wire braid hose suitable for grease and hydraulic oil applications. Maximum temperature 250o F.
HOSE* LESS HOSE
Model I.D. O.D. FT. SIZE
INDEX
(Chart)		 PSI APRX.
LBS.		 MODEL PSI APRX.
LBS.
EZ-P-HP-125 1/4” 1/2” 25 3 5000 50 EZ-P-HPL-125 5000 40

* Hose Information: DO NOT EXCEED our listed hose O.D.
to obtain maximum hose length or rated pressure.

EZ-SH, MP & HP SERIES
Heavy Duty Safety Reels

LOW PRESSURE COXREELS - The standard hose is for air or water service only. The basic reel without hose can be used for air, water or oil. Maximum temperature 150o Fahrenheit.
HOSE* LESS HOSE
Model I.D. O.D. FT. SIZE
INDEX
(Chart)		 PSI APRX.
LBS.		 MODEL PSI APRX.
LBS.
EZ-SH-350 3/8” 21/32” 50 4 300 60 EZ-SHL-350 300 52
EZ-SH-450 1/2” 21/32” 50 5 250 67 EZ-SHL-450 300 55
EZ-SH-525 3/4” 1-5/32” 25 6 250 64 EZ-SHL-525 300 55

MEDIUM PRESSURE COXREELS - - Reels are furnished standard with S.A.E. 100R1 AX thin cover one wire braid hose suitable for air, water or oil applications. Maximum temperature 250o F.
HOSE* LESS HOSE
Model I.D. O.D. FT. SIZE
INDEX
(Chart)		 PSI APRX.
LBS.		 MODEL PSI APRX.
LBS.
EZ-MP-450 1/2” 3/4” 50 5 2500 69 EZ-MPL-450 3000 58

HIGH PRESSURE COXREELS - Reels are furnished standard with S.A.E. 100R2 FX thin cover two wire braid hose suitable for grease and hydraulic oil applications. Maximum temperature 250o F.
HOSE* LESS HOSE
Model I.D. O.D. FT. SIZE
INDEX
(Chart)		 PSI APRX.
LBS.		 MODEL PSI APRX.
LBS.
EZ-HP-150 1/4” 1/2" 50 5 5000 71 EZ-HPL-150 5000 58
* Hose Information: DO NOT EXCEED our listed hose O.D.
to obtain maximum hose length or rated pressure.

EZ-T SERIES
Heavy Duty Large Capacity Safety Reels

LOW PRESSURE COXREELS - The standard hose is for air or water service only. The basic reel without hose can be used for air, water or oil. Maximum temperature 150o Fahrenheit.
HOSE* LESS HOSE
Model I.D. O.D. FT. SIZE
INDEX
(Chart)		 PSI APRX.
LBS.		 MODEL PSI APRX.
LBS.
EZ-TSH-375 3/8” 21/32” 75 9 300 90 EZ-TSHL-375 300 80
EZ-TSH-3100 3/8” 21/32” 100 9 300 97 EZ-TSHL-3100 300 81
EZ-TSH-475 1/2” 21/32” 75 9 300 92 EZ-TSHL-475 300 76
EZ-TSH-4100 1/2” 21/32” 100 9 300 102 EZ-TSHL-4100 300 81
EZ-TSH-550 3/4” 1-5/32” 50 11 250 94 EZ-TSHL-550 300 75

* Hose Information: DO NOT EXCEED our listed hose O.D.
to obtain maximum hose length or rated pressure.

 SIZE INDEX CHART
SIZE
INDEX
REEL DIMENSIONS
 MOUNT
L-M
A B C
D
E
1 6-1/4” 14-1/2” 13-3/4” 5” 6” 3" - 5”
2 6-1/8” 18-1/4” 13-1/4” 6” 6” 4” - 5”
3 7” 18-1/4” 17-1/4” 6” 6” 4” - 5”
4 8-3/4” 21” 19-5/8” 6” 6” 4” - 5”
5 9-1/4” 21” 19-5/8” 6” 6” 4” - 5”
6 9-3/4” 21” 19-5/8” 6” 6” 4” - 5”
7 9-1/4” 25-1/2” 23” 8” 9” 7” - 8”
8 9-3/4” 25-1/2” 23” 8” 9” 7” - 8”
