Includes heavy
duty features found in other popular COXREELS models. Benefits
include: ease of use, efficiency of application, stability, accessibility,
adaptability, and long service life. All components, including reel drums,
enclosure cases, bearings, axles, swivel joints, etc, are heavy-duty.
Totally enclosed reels are used indoors or outdoors where appearance and
or hose protection is required.
- REEL - See
specification on series "P" and series "SH-MP-HP"
- CABINET -
Heavy gauge steel enclosures consist of only three (3) pieces for
simplicity of installation and servicing. Hose rollers are field
adjustable.
The standard hose is for air or water service only. Consult
factory for other products. Maximum temperature with hose 150 degrees
Fahrenheit.
| DO
NOT USE WITH RATIO PUMP |
| MODEL |
HOSE |
PSI |
APPROX.
SHIP
WT. (lbs) |
SIZE
INDEX
(Chart) |
| I.D. |
O.D. |
FT. |
| EN-N-125 |
1/4" |
1/2" |
25 |
300 |
49 |
16 |
| EN-N-135 |
1/4" |
1/2" |
35 |
300 |
53 |
16 |
| EN-N-150 |
1/4" |
1/2" |
50 |
300 |
54 |
16 |
| EN-N-160 |
1/4" |
1/2" |
60 |
300 |
73 |
17 |
| EN-N-325 |
3/8" |
21/32" |
25 |
300 |
54 |
16 |
| EN-N-335 |
3/8" |
21/32" |
35 |
300 |
57 |
16 |
| EN-N-350 |
3/8" |
21/32" |
50 |
300 |
75 |
17 |
| EN-N-360 |
3/8" |
21/32" |
60 |
300 |
80 |
17 |
| EN-N-425 |
1/2" |
27/32" |
25 |
300 |
58 |
16 |
| EN-N-435 |
1/2" |
27/32" |
35 |
300 |
72 |
17 |
| EN-N-450 |
1/2" |
27/32" |
50 |
300 |
82 |
17 |
Reels are furnished standard with S.A.E. 100R1 AX thin cover, one
wire braid hose suitable for air, water or oil applications. Maximum
temperature 250 degrees Fahrenheit.
| MODEL |
HOSE |
PSI |
APPROX.
SHIP
WT. (lbs) |
SIZE
INDEX
(Chart) |
| I.D. |
O.D. |
FT. |
| ENM-N-325 |
3/8" |
5/8" |
25 |
3000 |
56 |
16 |
| ENM-N-335 |
3/8" |
5/8" |
35 |
3000 |
58 |
16 |
| ENM-N-350 |
3/8" |
5/8" |
50 |
3000 |
82 |
17 |
| ENM-N-425 |
1/2" |
3/4" |
25 |
2500 |
57 |
16 |
| ENM-N-435 |
1/2" |
3/4" |
35 |
2500 |
74 |
17 |
| ENM-N-450 |
1/2" |
3/4" |
50 |
2500 |
85 |
17 |
Reels are furnished standard with S.A.E. 100R2 FX thin cover two
wire braid hose suitable for grease and hydraulic oil applications.
Maximum temperature 250 degrees Fahrenheit.
| MODEL |
HOSE |
PSI |
APPROX.
SHIP
WT. (lbs) |
SIZE
INDEX
(Chart) |
| I.D. |
O.D. |
FT. |
| ENH-N-125 |
1/4" |
17/32" |
25 |
5000 |
57 |
16 |
| ENH-N-135 |
1/4" |
17/32" |
35 |
5000 |
59 |
16 |
| ENH-N-150 |
1/4" |
17/32" |
50 |
5000 |
87 |
17 |
| ENH-N-160 |
1/4" |
17/32" |
60 |
5000 |
91 |
17 |
| ENH-N-325 |
3/8" |
43/64" |
25 |
4000 |
59 |
16 |
| ENH-N-335 |
3/8" |
43/64" |
35 |
4000 |
76 |
17 |
| ENH-N-350 |
3/8" |
43/64" |
50 |
4000 |
86 |
17 |
HOSE
INFO: DO NOT EXCEED OUR LISTED HOSE O.D.
TO OBTAIN MAXIMUM USABLE HOSE
LENGTH.
SIZE
INDEX |
OVERALL REEL
DIMENSIONS |
| WIDTH |
HEIGHT |
LENGTH |
| 16 |
7" |
18-3/4" |
18-3/4" |
| 17 |
9-1/4" |
21-3/4" |
21-3/4" | |
