NOTE: Hose Roller
Guide Assembly Shown is Sold Separately
COXREELS'
large capacity, hand-crank welding reels are perfect for applications
that require long lengths of hose. Each reel is built using the highest
quality, heavy-guage materials.
- Suitable for
Oxy-Axetelene and "T" Grade Applications
- Used for a
wide variety of gases such as MAPP, gas, propane gas, natural gas, and
fuel gases.
- Model
1275W-3-150-C PS is portable with PR Series Portable Reel Cart
Model No. PR-1125-12.
- Swivels come
standard equipped with 3/8" right and left hand welding fittings.
- Bevel gear
and removable handle for compact storage such as cabinet
mounting.
- Long-handled
lock pin secures the reel, preventing unwinding while not in use.
| MODEL |
OVERALL
DIMENSION |
HOSE |
LESS HOSE |
| HEIGHT |
WIDTH |
DEPTH
w/handle |
WT
LBS. |
PSI |
ID |
OD |
LENGTH |
MODEL |
WT.
LBS. |
PSI |
| 1275W-3-100-C |
18-1/8" |
18-7/8 |
23-3/4" |
65 |
200 |
3/8" |
.66" |
100 |
1275WL-3-100-C |
37 |
3000 |
| 1275W-3-150-C |
18-1/8" |
22-7/8 |
23-3/4" |
80 |
200 |
3/8" |
.66" |
150 |
1275WL-3-150-C |
38 |
3000 |
| 1275W-3-250-C |
18-1/8" |
28-7/8 |
23-3/4" |
114 |
200 |
3/8" |
.66" |
250 |
1275WL-3-250-C |
44 |
3000 |
| -- |
18-1/8" |
34-7/8 |
23-3/4" |
-- |
-- |
-- |
-- |
-- |
1275WL-3-350-C |
53 |
3000 | |
|
