COXREELS Challenger Reels offer high performance in a very compact and lightweight hand crank hose reel. Perfect for both the mobile application, where size and weight are important factors, and permanent mounting on the wall, floor or workbench. Designed for use in pressure washer, steam-cleaning and spray operations, as well as washdown and compressed air.

  • Direct Hand Crank Rewind
  • Lightweight/Compact
  • Standard 4,000 psi Working Pressure
  • Reels Handle Product Temperatures from -20 Degrees Fahrenheit to +225 Degrees Fahrenheit
  • Full Flow 90 Degree Brass Swivel
  • Adjustable Drag Brake to Eliminate Hose Backlash While Unreeling Hose

I.D. X O.D.  MODEL INLET &
OUTLET
SIZE N.P.T.		 REEL DIMENSIONS
in Inches (E, C & G are
Overall Dimensions		 SHIP
WEIGHT (lbs)
1/4" x 5/8"  3/8" x 3/4" 1/2" x 7/8" WIDTH HEIGHT LENGTH
  100   112-3-100 3/8" 15-1/4"  13" 12" 18.5
  150   112-3-150 3/8"  19-3/4" 13" 12" 21
  250   117-3-250 3/8" 15-1/4" 18" 17" 30
  400 . 117-3-400  3/8"  19-3/4" 18" 17" 33
  550   117-3-550 3/8" 24-1/4" 18" 17" 36.5
    75 112-4-75 1/2" 20" 13" 12" 21
    225 117-4-225 1/2" 20" 18" 17" 33
    350 117-4-350 1/2" 24-1/2" 18" 17" 36.5
