- Discs: Heavy
gauge steel with rolled edges to add strength and eliminate hose
damage
- Solid Frame,
All Steel
- Rewind Hand
Crank: Solid steel with a roller hand grip
- Rewind
Motor: Electric rewind motor is shown. Compressed air or hydraulic
motors also available
- Swivel
Joint: Permits reel to rotate smoothly while connected to the fluid
source.
Brass and steel are used as standard for swivel joint
inlets.
Stainless steel and other alloys can be supplied to meet
special requirements.
- Bearing:
Self-aligning pillow block bearings support the drum assembly
- Rewind
Mechanism: Positive chain drive on all power rewind reels.
- Drum
Assembly, All Steel
- Axle/Riser
Assembly: Provides full flow through the internal plumbing
- Lock Pin:
Standard on hand crank models, available at extra cost on power
rewind.
- Tension
Brake: Standard on hand crank models.
REWIND: Hand crank attaches to
the axle and is permanent or removable at the user's option.
| INLET SWIVEL ASSEMBLY: |
| SERIES |
SWIVEL ASSEMBLY |
| 1125-4 Series |
1/2"
female N.P.T. 90 Degrees |
| 1125-5 Series |
3/4"
female N.P.T. 90 Degrees |
| 1125-6 Series |
1"
female N.P.T. 90 Degrees |
| 1175-6 Series |
1"
female N.P.T. 90 Degrees |
| 1175-8 Series |
1-1/2" female N.P.T.
straight |
| OUTLET RISER: |
| SERIES |
RISER |
| 1125-4 Series |
1/2"
female N.P.T. |
| 1125-5 Series |
3/4"
female N.P.T. |
| 1125-6 Series |
1"
female N.P.T. |
| 1175-6 Series |
1"
female N.P.T. |
| 1175-8 Series |
1-1/2" female
N.P.T. |
Garden hose
thread available; consult factory.
HOSE ROLLER GUIDES: See Assemblies & Components
For Details.
PRODUCT TEMPERATURES: These reels handle
product temperatures from -20
Degrees to +225 Degrees Fahrenheit.
Other temperatures or pressures can be furnished.
See price sheet or
consult factory.
CAUTION:
To prevent drum damage, fully extend and pressurize hose before winding on
reel.
HOSE CAPACITY OF REEL
"I.D X
O.D." |
MODEL |
IN. &
OUT.
N.P.T. |
WORK.
PRES.
P.S.I. |
REEL DIMENSIONS |
SHIP
WGT.
(lbs) |
3/8"
x
3/4" |
1/2"
x
7/8" |
3/4"
x
1-1/4" |
1"
x
1-7/16" |
1-1/4"
x
1-13/16" |
1-1/2"
x
2-1/16" |
WIDTH
(CRANK) |
WIDTH
(ELEC.) |
WIDTH
(AIR) |
LGTH. |
HT. |
| 140 |
100 |
. |
. |
. |
|
1125-4-100 |
1/2" |
3000 |
21-3/4" |
18-3/8" |
16-1/2" |
17" |
18-1/8" |
36 |
| 300 |
200 |
. |
. |
. |
. |
1125-4-200 |
1/2" |
3000 |
27-3/4" |
24-3/8" |
22-1/2" |
17" |
18-1/8" |
38 |
| 450 |
325 |
|
|
|
|
1125-4-325 |
1/2" |
3000 |
33-3/4" |
30-3/8" |
28-1/2" |
17" |
18-1/8" |
43 |
| 625 |
450 |
|
|
|
|
1125-4-450 |
1/2" |
3000 |
39-3/4" |
36-3/8" |
34-1/2" |
17" |
18-1/8" |
52 |
| 700 |
500 |
|
|
|
|
1125-4-500 |
1/2" |
3000 |
43-3/4" |
40-3/8" |
38-1/2" |
17" |
18-1/8" |
58 |
| |
100 |
50 |
|
|
|
1125-5-50 |
3/4" |
3000 |
21-1/4" |
18-3/8" |
16-1/2" |
17" |
18-1/8" |
37 |
| |
200 |
100 |
|
|
|
1125-5-100 |
3/4" |
3000 |
27-1/4" |
24-3/8" |
22-1/2" |
17" |
18-1/8" |
39 |
| |
325 |
175 |
|
|
|
1125-5-175 |
3/4" |
3000 |
33-1/4" |
30-3/8" |
28-1/2" |
17" |
18-1/8" |
44 |
| |
450 |
200 |
|
|
|
1125-5-200 |
3/4" |
3000 |
39-1/4" |
36-3/8" |
34-1/2" |
17" |
18-1/8" |
53 |
| |
500 |
250 |
|
|
|
1125-5-250 |
3/4" |
3000 |
43-1/4" |
40-3/8" |
38-1/2" |
17" |
18-1/8" |
59 |
|
|
|
35 |
|
|
1125-6-35 |
1" |
1000 |
24-3/4" |
21-7/8" |
20" |
15-1/8" |
18-1/2" |
51 |
|
|
100 |
50 |
|
|
1125-6-50 |
1" |
1000 |
30-3/4" |
27-7/8" |
26" |
15-1/8" |
18-1/2" |
56 |
|
|
125 |
75 |
|
|
1125-6-75 |
1" |
1000 |
37-1/4" |
34-3/8" |
32-1/2" |
15-1/8" |
18-1/2" |
62 |
|
|
150 |
100 |
|
|
1125-6-100 |
1" |
1000 |
43-1/4" |
40-3/8" |
38-1/2" |
15-1/8" |
18-1/2" |
67 |
| |
|
100 |
50 |
|
|
1175-6-50 |
1" |
1000 |
24-3/4" |
20-3/8" |
18-1/2" |
24" |
26-1/4" |
90 |
| |
|
150 |
100 |
|
|
1175-6-100 |
1" |
1000 |
28-3/4" |
24-3/8" |
22-1/2" |
24" |
26-1/4" |
98 |
| |
|
200 |
125 |
|
|
1175-6-125 |
1" |
1000 |
30-3/4" |
26-3/8" |
24-1/2" |
24" |
26-1/4" |
102 |
| |
|
250 |
150 |
|
|
1175-6-150 |
1" |
1000 |
32-3/4" |
28-3/8" |
26-1/2" |
24" |
26-1/4" |
106 |
| |
|
300 |
200 |
|
|
1175-6-200 |
1" |
1000 |
37-1/4" |
32-7/8" |
31" |
24" |
26-1/4" |
115 |
| |
|
|
. |
75 |
50 |
1175-8-50 |
1-1/2" |
600 |
24-1/16" |
- |
- |
24" |
27" |
118 |
| |
|
|
|
100 |
75 |
1175-8-75 |
1-1/2" |
600 |
28-1/16" |
- |
- |
24" |
27" |
124 |
| |
|
|
|
125 |
100 |
1175-8-100 |
1-1/2" |
600 |
32-9/16" |
- |
- |
24" |
27" |
133 |
| |
|
|
|
180 |
125 |
1175-8-125 |
1-1/2" |
600 |
32-9/16" |
- |
- |
28" |
30" |
158 |
| |
|
|
|
220 |
150 |
1175-8-150 |
1-1/2" |
600 |
37-9/16" |
- |
- |
28" |
30" |
170 |
See Assemblies & Components
for the proper motor and electrical components & when
ordering
power rewind models, suffix the above model number with the proper motor
suffix.
A – AIR REWIND, No. 4 Gast, Compressed
Air Motor
E – ELECTRIC DC, Non Exp. Proof, 1/3
H.P. Rewind, Reversible Type
ED – ELECTRIC DC, Explosion Proof, 1/2
H.P. Rewind, Reversible Type
EA – ELECTRIC AC, Explosion Proof, 115
V, 1/2 H.P. Rewind, AC Motor, Reversible |
