COXREELS DOLLY FEATURES &
BENEFITS | |
|
|
|
|
Series DM |
- All
steel construction
- Solid
8" rubber tires
- Heavy
duty 1-1/4" round tube frame structure
- Removable handle
for compact shipping or storage
- Rubber
front feet to prevent reel from slipping forward when pulling out
the hose
- Adjustable drag
brake to prevent hose backlash when unreeling
- Full
flow 90° brass swivel inlet
- Garden
kit - optional: includes hookup hose with garden (F) swivel end
& (M) garden thread to attach the main hose
| |
|
HOSE CAPACITY
OF REEL
"L.D X
O.D." |
MODEL
NUMBER |
INLET
AND
OUTLET
SIZE
N.P.T.
(INCHES) |
REEL DIMENSIONS IN INCHES
E, F AND G
ARE OVERALL DIMENSIONS |
APPRX.
LBS. |
| I.D. |
3/8" |
1/2" |
| O.D. |
3/4" |
7/8" |
A |
B |
C |
D |
E |
F |
G |
- |
| |
200 |
|
117-3-200DM |
3/8" |
5
1/2" |
8" |
17" |
12
1/4" |
20
3/8" |
40" |
19" |
37 |
| |
325 |
225 |
117-4-225DM |
1/2" |
5
1/2" |
12
1/2" |
17" |
16
3/4" |
24
7/8" |
40" |
19" |
39 | |
|
|
COXREELS CADDY FEATURES &
BENEFITS | |
|
|
|
Series CM |
- All
steel construction
- Heavy
duty 1" round tube frame structure
- Rigid
1" diameter round handle for carrying to work site
- Adjustable drag
brake to prevent hose backlash when unreeling
- Reels
have large mounting base for permanent installations
- Full
flow 90° brass swivel inlet
- Hose
control bar to prevent the hose from slipping off the side discs
when pulling from an angle
- Roof
anchor - optional: to securely fix the caddy to the roof top for
contractor use
| |
|
HOSE CAPACITY
OF REEL
"L.D X
O.D." |
MODEL
NUMBER |
INLET
AND
OUTLET
SIZE
N.P.T.
(INCHES) |
REEL DIMENSIONS IN INCHES
E, F AND G ARE OVERALL
DIMENSIONS |
APPRX.
LBS. |
| I.D. |
3/8" |
1/2" |
| O.D. |
3/4" |
7/8" |
A |
B |
C |
D |
E |
F |
G |
L |
M |
- |
| |
100 |
|
112-3-100CM |
3/8" |
5
1/2" |
8" |
12" |
12" |
18
3/8" |
13" |
13
3/4" |
3" |
6" |
22 |
| |
150 |
|
112-3-150CM |
3/8"" |
5
1/2" |
12
1/2" |
12" |
16
1/2" |
22
7/8" |
13" |
13
3/4" |
3" |
10
1/2" |
25 |
| |
325 |
225 |
117-4-225CM |
1/2" |
5
1/2" |
12
1/2" |
17" |
16
1/2" |
23
1/8" |
17
3/4" |
19" |
3" |
10
1/2" |
30 | |
|
|
|
|
|
|
|
|
|
|
|
|
|
