FEATURES

• Wall or Machine Mount - choose from four unique mounting brackets easily adaptable for almost any swivel mount situation. If your needs require special attention, Coxreels will custom design and manufacture a bracket to your specifications.
• Unique Hose Control Bar - spans the width of the reel and allows hose to be pulled from any direction without slipping off the reel.
• Single Piece U-Shaped Frame Design - provides maximum structural strength for durability as well as lightweight convenience.
• Direct Hand Crank - a solid steel crank arm equipped with a smooth, tapered, plastic handgrip designed for easy operator use and safety.
• 8-Position Locking Pin - stabilizes reel position to allow hassle-free use in mobility and rewinding.
• Adjustable Hand Brake - tightens down drum and locks to prevent uncoiling and hose backlash while unreeling.
• Full Flow 90 Degrees Brass Swivel - designed with corrosion resistant brass to rotate under minimum torque ensuring smooth hose retraction and maximum flow.
• Gloss Black Polyester Powder Coat Finish - protects against damage caused by UV rays, chipping, scratching, and general use.
• Handles Product Temperatures - from -20 degrees to 300 degrees F and 4,000 PSI Standard Working Pressure.

OPTIONAL MOUNTING BRACKET

SMK-202 mounting bracket designed for convenient mounting. Pivoting base rotates on a composite sleeve for a smooth and non-corrosive environment. Locking pins lock in 8 positions to hold the reel securely for easy rewinding capabilities. Coxreels will custom design and manufacture any bracket to meet your specifications. Contact us for more information regarding custom designs.
