First
reel and second reel are supplied standard with the same hose: Two
air-water hose assemblies, two medium pressure hose assemblies, or
two high pressure hose assemblies.
Reels
operate independently of each other and may be serviced independently.
- Heavy
duty 1/4" plate steel support post and mounting plate
- 1"
solid steel center support shaft
- 1"
oil-lite self-lubricating bearing
- Full
flow swivel joint
- Adjustable arm guide (wall, floor, ceiling and pit)
- Cartridge style spring motor
- 4-roller, non-snag hose guide
- 8-position locking ratchet (each reel)
The standard hose is for air or water service only. The basic reel
without hose can be used for air, water or oil. Consult factory
for other products. Maximum temperature with hose 150 degrees
Fahrenheit.
| DO
NOT USE WITH RATIO PUMP |
| MODEL |
HOSE |
PSI |
APPRX.
SHIP
WT. (lbs) |
SIZE
INDEX
(Chart) |
LESS HOSE |
| I.D. |
O.D. |
FT. |
MODEL |
PSI |
APPRX.
WT. (lbs) |
| C-LP-125-125 |
1/4" |
1/2" |
25 |
300 |
73 |
19 |
C-LPL-125-125 |
300 |
67 |
| C-LP-135-135 |
1/4" |
1/2" |
35 |
300 |
76 |
19 |
C-LPL-135-135 |
300 |
67 |
| C-LP-150-150 |
1/4" |
1/2" |
50 |
300 |
78 |
19 |
C-LPL-150-150 |
300 |
67 |
| C-LP-325-325 |
3/8" |
21/32" |
25 |
300 |
78 |
14 |
C-LPL-325-325 |
300 |
67 |
| C-LP-335-335 |
3/8" |
21/32" |
35 |
300 |
82 |
14 |
C-LPL-335-335 |
300 |
67 |
| C-LP-350-350 |
3/8" |
21/32" |
50 |
300 |
88 |
14 |
C-LPL-350-350 |
300 |
67 |
| C-LP-425-425 |
1/2" |
27/32" |
25 |
300 |
85 |
15 |
C-LPL-425-425 |
300 |
68 |
Reels are furnished standard with S.A.E. 100R1 AX thin cover, one
wire braid hose suitable for air, water or oil applications. Maximum
temperature 250 degrees Fahrenheit.
| MODEL |
HOSE |
PSI |
APPRX.
SHIP
WT. (lbs) |
SIZE
INDEX
(Chart) |
LESS HOSE |
| I.D. |
O.D. |
FT. |
MODEL |
PSI |
APPRX.
WT. (lbs) |
| C-MP-325-325 |
3/8" |
5/8" |
25 |
3000 |
80 |
15 |
C-MPL-325-325 |
3000 |
68 |
| C-MP-335-335 |
3/8" |
5/8" |
35 |
3000 |
84 |
15 |
C-MPL-335-335 |
3000 |
68 |
| C-MP-425-425 |
1/2" |
3/4" |
25 |
2500 |
83 |
15 |
C-MPL-425-425 |
2500 |
68 |
| C-MP-430-430 |
1/2" |
3/4" |
30 |
2500 |
85 |
15 |
C-MPL-430-430 |
2500 |
68 |
Reels are furnished standard with S.A.E. 100R2 FX thin cover two
wire braid hose suitable for grease and hydraulic oil applications.
Maximum temperature 250 degrees Fahrenheit.
| MODEL |
HOSE |
PSI |
APPRX.
SHIP
WT. (lbs) |
SIZE
INDEX
(Chart) |
LESS HOSE |
| I.D. |
O.D. |
FT. |
MODEL |
PSI |
APPRX.
WT. (lbs) |
| C-HP-125-125 |
1/4" |
17/32" |
25 |
5000 |
82 |
15 |
C-HPL-125-125 |
5000 |
68 |
| C-HP-135-135 |
1/4" |
17/32" |
35 |
5000 |
87 |
15 |
C-HPL-135-135 |
5000 |
68 |
| C-HP-325-325 |
3/8" |
43/64" |
25 |
4000 |
85 |
15 |
C-HPL-325-325 |
4000 |
68 |
| C-HP-330-330 |
3/8" |
43/64" |
30 |
4000 |
88 |
15 |
C-HPL-330-330 |
4000 |
68 |
HOSE
INFO: DO NOT EXCEED OUR LISTED HOSE O.D.
TO OBTAIN MAXIMUM HOSE LENGTH.
SIZE
INDEX |
OVERALL REEL DIMENSIONS |
| WIDTH |
HEIGHT |
LENGTH |
| 14 |
11-1/8" |
18-1/4" |
17-1/4" |
| 15 |
12-1/2" |
18-1/4" |
17-1/4" |
| 19 |
10-1/2" |
18-1/4" |
17-1/4" |
|
