SPRING RETRACTABLE HOSE REEL

ELECTRO-POLISHED

The electrolytic polishing process gives an aesthetically lustrous mirror-like finish while providing additional protection against corrosion and contamination.

MODEL Less Hose	HOSE			PSI	APPRX. SHIP WT. (lbs)	SIZE INDEX (Chart)
	I.D.	O.D.	FT.
P-LPL-335-SS	3/8"	21/32"	35	300	39	3
P-LPL-425-SS	1/2"	27/32"	25	300	40	4
SHL-N-350-SS	3/8"	21/32"	50	300	55	5
SHL-N-450-SS	1/2"	27/32"	50	300	58	6
SHL-N-525-SS	3/4"	1"	25	300	62	6
TSHL-N-4100-SS	1/2"	27/32"	100	300	81	9
TSHL-N-550-SS	3/4"	21/32"	50	300	75	10
MPL-N-350-SS	3/8"	5/8"	50	3000	60	6
MPL-N-450-SS	1/2"	3/4"	50	2500	60	6
ENL-N-335-SS	3/8"	21/32"	35	300	57	7
ENL-N-350-SS	3/8"	21/32"	50	300	73	8
ENL-N-450-SS	1/2"	27/32"	50	300	80	8

HOSE INFO: DO NOT EXCEED OUR LISTED HOSE O.D.
TO OBTAIN MAXIMUM USABLE HOSE LENGTH.

HAND CRANK HOSE REEL

ELECTRO-POLISHED

The electrolytic polishing process gives an aesthetically lustrous mirror-like finish while providing for additional protection against corrosion and contamination.

MODEL Less Hose	HOSE			PSI	APPRX. SHIP WT. (lbs)	SIZE INDEX (Chart)
	I.D.	O.D.	FT.
112-4-75-SS	1/2"	7/8"	75	3,000	21	1
117-4-225-SS	1/2"	7/8"	225	3,000	33	2
117-5-100-SS	3/4"	1-1/4"	100	3,000	36	3

HOSE INFO: DO NOT EXCEED OUR LISTED HOSE O.D.
TO OBTAIN MAXIMUM USABLE HOSE LENGTH.

SIZE CHART INDEX

SIZE INDEX	OVERALL REEL DIMENSIONS
	WIDTH	HEIGHT	LENGTH
1	20"	13"	12"
2	20"	18"	17"
3	20-1/2"	18"	17"
5	8-3/4"	21"	19-5/8"
6	9-1/4"	21"	19-5/8"
7	7"	18 3/4"	18 3/4"
8	9-1/4"	21-3/4"	21-3/4"
9	9-1/4"	25-1/2"	23"
10	9-3/4"	21-3/16"	19-5/8"
