COXREELS high capacity reels are designed for high volume delivery of air, water and oil at low and medium pressures. Constructed in heavy gauge powder coated steel, SP reels are suitable for use in fixed applications or on mobile service vehicles where longer lengths or larger diameters of hose are necessary, but the convenience of spring rewind is still required. The roller guide can be set for floor, wall or overhead installation.

  • Heavy Duty Steel Construction With Durable Blue Powder Finish
  • Double Supported Steel Axle
  • Stainless Steel Roller Guides Reduce Hose Wear
  • Reinforced Steel Frame for Maximum Stability
  • Drilled Mounting Holes for Easy Installation
  • Fully Automatic Hose Rewind for Neat and Tidy Storage
  • Externally Mounted Full-flow Swivel for Maximum Product Delivery
  • All Working Parts Easily Accessible for Servicing

 SERIES SP: SINGLE HOSE, SPRING REWIND - LOW PRESSURE COXREELS

For applications 250 to 2000 psi and temperatures to 225 degrees Fahrenheit. Note: For higher temperatures and pressures, consult factory. Two Braid Hose - Maximum Pressure 300 psi.
WITH HOSE
  HOSE
 REEL DIMENSIONS INLET &
OUTLET SIZE
N.P.T.		 LESS HOSE
MODEL WEIGHT
(lbs)		 I.D.  O.D. FT. WIDTH HEIGHT LENGTH MODEL WEIGHT
(lbs)
SLP-4100 154 1/2" 7/8" 100 19-1/2" 20-1/2" 24-7/8" 1/2" SLPL-4100 130
SLP-550 130 3/4" 1-1/4" 50 19"  20-1/2" 24-7/8" 3/4" SLPL-550 110
SLP-550* 135 3/4" 1-1/4" 50 19" 20-1/2" 24-7/8" 3/4" SLPL-550 110
SLP-575 154 3/4" 1-1/4" 75 19" 24-1/2" 28-3/8" 3/4" SLPL-575 125
SLP-5100 183 3/4" 1-1/4" 100 20" 24-1/2" 28-3/8" 3/4" SLPL-5100 145
SLP-625 123 1" 1-7/16" 25 20-1/2" 20-1/2" 24-7/8" 1" SLPL-625 105
SLP-650 140 1" 1-7/16" 50 21" 24-1/2" 28-3/8" 1" SLPL-650 110
SLPF-650* 145 1" 1-7/16" 50 21" 24-1/2" 28-3/8" 1" SLPL-650 110
SLP-675 174 1" 1-7/16" 75 21" 28-1/2" 28-3/8" 1" SLPL-675 130
Consult Factory
For Reels With Hose		 1-1/4" 1-13/16" 25 18" 24-1/2" 32-3/8" 1-1/2" SLPL-725 105
1-1/2" 1-13/16" 50 18" 28-1/2" 28-3/8" 1-1/2" SLPL-750 115
1-1/4" 2-1/16" 25 18" 24-1/2" 32-3/8" 1-1/2" SLPL-825 105
1-1/2" 2-1/16" 35 18" 28-1/2" 32-3/8" 1-1/2" SLPL-835 132
*These reels supplied with fuel hose.

 SERIES SP: SINGLE HOSE, SPRING REWIND - MEDIUM PRESSURE COXREELS

For applications 250 to 2000 psi and temperatures to 225 degrees Fahrenheit. Note: For higher temperatures and pressures, consult factory. 100 RI Hose - Maximum Pressure 2000 psi.
WITH HOSE
  HOSE
 REEL DIMENSIONS INLET &
OUTLET SIZE
N.P.T.		 LESS HOSE
MODEL  WEIGHT
(lbs)		 I.D.  O.D. FT. WIDTH HEIGHT LENGTH MODEL WEIGHT
(lbs)
SMP-4100 160 1/2" 29/32" 100 19-1/2" 20-1/2" 24-7/8" 1/2" SMPL-4100 130
SMP-550 142 3/4" 1-3/16" 50 20-1/2" 20-1/2" 24-7/8" 3/4" SMPL-550 115
SMP-575 164 3/4" 1-3/16" 75 21" 24-1/2" 28-3/8" 3/4" SMPL-575 125
SMP-5100 196 3/4" 1-3/16" 100 21" 24-1/2" 28-3/8" 3/4" SMPL-5100 145
Consult Factory
For Reels With Hose		 1" 1-1/2"  25 20-1/2" 20-1/2" 24-7/8" 1" SMPL-625 110
1" 1-1/2" 50 21" 24-1/2" 28-3/8" 1" SMPL-650 115
1" 1-1/2" 75 21" 28-1/2" 32-3/8" 1" SMPL-675 135

 SERIES DP: DUAL HOSE, SPRING REWIND - LOW PRESSURE COXREELS

Series "DP" reels have two swivel joint inlets and two outlet risers to simultaneously handle equal lengths of two hoses. Hoses can be different diameters, in which case the larger hose diameter determines capacity of the reel. For applications 300 to 2500 psi and temperatures to 225 degrees Fahrenheit. Note: For higher temperatures and pressures, consult factory. Two Braid Hose - Maximum Pressure 300 psi.
WITH HOSE HOSE  REEL DIMENSIONS INLET &
OUTLET SIZE
N.P.T.		 LESS HOSE
MODEL WEIGHT
(lbs)		 I.D.  O.D. FT. WIDTH HEIGHT LENGTH MODEL WEIGHT
(lbs)
Consult Factory
For Reels With Hose		 3/8" 3/4" 50 22" 20-1/2" 24-7/8" 1/2" DLPL-350 110
3/8" 3/4" 75 22" 20-1/2" 24-7/8" 1/2" DLPL-375 115
3/8" 3/4" 100 22-1/2" 24-1/2" 28-3/8" 1/2" DLPL-3100 145
1/2" 7/8" 50 22" 20-1/2" 24-7/8" 1/2" DLPL-450 115
1/2" 7/8" 75 22-1/2" 24-1/2" 28-3/8" 1/2" DLPL-475 125
1/2" 7/8" 100 22-1/2" 28-1/2" 32-3/8" 1/2" DLPL-4100 145
3/4" 1-1/4" 25 23-3/4" 20-1/2" 24-7/8" 3/4" DLPL-525 110
3/4" 1-1/4" 50 23-3/4" 24-1/2" 28-3/8" 3/4" DLPL-550 120

 SERIES DP: DUAL HOSE, SPRING REWIND - MEDIUM PRESSURE COXREELS

Series "DP" reels have two swivel joint inlets and two outlet risers to simultaneously handle equal lengths of two hoses. Hoses can be different diameters, in which case the larger hose diameter determines capacity of the reel. For applications 300 to 2500 psi and temperatures to 225 degrees Fahrenheit. Note: For higher temperatures and pressures, consult factory.100 RI Hose - Maximum Pressure 2500 psi.
WITH HOSE HOSE  REEL DIMENSIONS INLET & OUTLET SIZE
N.P.T.		 LESS HOSE
MODEL WEIGHT
(lbs)		 I.D.  O.D. FT. WIDTH HEIGHT LENGTH MODEL WEIGHT
(lbs)
Consult Factory
For Reels With Hose		 3/8" 25/32" 50 22-1/2" 20-1/2" 24-7/8" 1/2" DMPL-350 110
3/8" 25/32" 75 22-1/2" 20-1/2" 24-7/8" 1/2" DMPL-375 115
3/8" 25/32" 100 22-1/2" 24-1/2" 28-3/8" 1/2" DMPL-3100 145
1/2" 29/32" 50 22-1/2" 20-1/2" 24-7/8" 1/2" DMPL-450 115
1/2" 29/32" 75 22-1/2" 24-1/2" 28-3/8" 1/2" DMPL-475 125
1/2" 29/32" 100 22-1/2" 28-1/2" 32-3/8" 1/2" DMPL-4100 145
