Compact Space-Savers! Versatile! Convenient! High quality,
compact design to handle general air and water applications that require
shorter lengths of hose.
COXREELS
incorporates modern engineering and manufacturing techniques to assure
maximum product performance. This newly designed performance reel offers
tested and proven heavy duty component parts found in other popular
COXREELS models.
- Heavy
duty 1/4" plate steel support post and mounting plate
- 1"
oil-lite self-lubricating bearing
- 1"
solid steel center support shaft
- Full
flow swivel joint
- Adjustable arm guide (wall, floor, ceiling and pit)
- Cartridge style spring motor
- 4-roller, non-snag hose guide
- 8-position locking ratchet
The standard hose is for air or water service only. The basic
reel without hose can be used for air, water or oil. Maximum temperature
with hose 150 degrees Fahrenheit.
| DO NOT USE WITH RATIO
PUMP |
| MODEL |
HOSE |
PSI |
APPRX.
SHIP
WT. (lbs) |
SIZE
INDEX
(Chart) |
LESS HOSE |
| I.D. |
O.D. |
FT. |
MODEL |
PSI |
APPRX.
WT. (lbs) |
| P-LP-110 |
1/4" |
1/2" |
10 |
300 |
29 |
1 |
P-LPL-110 |
300 |
26 |
| P-LP-115 |
1/4" |
1/2" |
15 |
300 |
29 |
1 |
P-LPL-115 |
300 |
26 |
| P-LP-125 |
1/4" |
1/2" |
25 |
300 |
32 |
1 |
P-LPL-125 |
300 |
28 |
| P-LP-130 |
1/4" |
1/2" |
30 |
300 |
35 |
1 |
P-LPL-130 |
300 |
30 |
| P-LP-135 |
1/4" |
1/2" |
35 |
300 |
36 |
1 |
P-LPL-135 |
300 |
30 |
| P-LP-140 |
1/4" |
1/2" |
40 |
300 |
45 |
3 |
P-LPL-140 |
300 |
39 |
| P-LP-150 |
1/4" |
1/2" |
50 |
300 |
46 |
3 |
P-LPL-150 |
300 |
39 |
| P-LP-310 |
3/8" |
21/32" |
10 |
300 |
30 |
2 |
P-LPL-310 |
300 |
26 |
| P-LP-315 |
3/8" |
21/32" |
15 |
300 |
31 |
2 |
P-LPL-315 |
300 |
26 |
| P-LP-325 |
3/8" |
21/32" |
25 |
300 |
35 |
2 |
P-LPL-325 |
300 |
28 |
| P-LP-330 |
3/8" |
21/32" |
30 |
300 |
47 |
3 |
P-LPL-330 |
300 |
39 |
| P-LP-335 |
3/8" |
21/32" |
35 |
300 |
48 |
3 |
P-LPL-335 |
300 |
39 |
| P-LP-340 |
3/8" |
21/32" |
40 |
300 |
49 |
3 |
P-LPL-340 |
300 |
39 |
| P-LP-350 |
3/8" |
21/32" |
50 |
300 |
51 |
3 |
P-LPL-350 |
300 |
39 |
| P-LP-415 |
1/2" |
27/32" |
15 |
300 |
44 |
4 |
P-LPL-415 |
300 |
39 |
| P-LP-425 |
1/2" |
27/32" |
25 |
300 |
49 |
4 |
P-LPL-425 |
300 |
40 |
| P-LP-430 |
1/2" |
27/32" |
30 |
300 |
49 |
4 |
P-LPL-430 |
300 |
40 |
Reels are furnished standard with S.A.E. 100R1 AX thin cover one
wire braid hose suitable for air, water or oil applications. Maximum
temperature 250 degrees Fahrenheit.
| MODEL |
HOSE |
PSI |
APPRX.
SHIP
WT. (lbs) |
SIZE
INDEX
(Chart) |
LESS HOSE |
| I.D. |
O.D. |
FT. |
MODEL |
PSI |
APPRX.
WT. (lbs) |
| P-MP-320 |
3/8" |
5/8" |
20 |
3000 |
46 |
4 |
P-MPL-320 |
3000 |
40 |
| P-MP-325 |
3/8" |
5/8" |
25 |
3000 |
47 |
4 |
P-MPL-325 |
3000 |
40 |
| P-MP-330 |
3/8" |
5/8" |
30 |
3000 |
48 |
4 |
P-MPL-330 |
3000 |
40 |
| P-MP-335 |
3/8" |
5/8" |
35 |
3000 |
49 |
4 |
P-MPL-335 |
3000 |
40 |
| P-MP-420 |
1/2" |
3/4" |
20 |
2500 |
47 |
4 |
P-MPL-420 |
2500 |
40 |
| P-MP-425 |
1/2" |
3/4" |
25 |
2500 |
48 |
4 |
P-MPL-425 |
2500 |
40 |
| P-MP-430 |
1/2" |
3/4" |
30 |
2500 |
49 |
4 |
P-MPL-430 |
2500 |
40 |
Reels are furnished standard with S.A.E. 100R2 FX thin cover two
wire braid hose suitable for grease and hydraulic oil applications.
Maximum temperature 250 degrees Fahrenheit.
| MODEL |
HOSE |
PSI |
APPRX.
SHIP
WT. (lbs) |
SIZE
INDEX
(Chart) |
LESS HOSE |
| I.D. |
O.D. |
FT. |
MODEL |
PSI |
APPRX.
WT. (lbs) |
| P-HP-120 |
1/4" |
17/32" |
20 |
5000 |
46 |
4 |
P-HPL-120 |
5000 |
40 |
| P-HP-125 |
1/4" |
17/32" |
25 |
5000 |
48 |
4 |
P-HPL-125 |
5000 |
40 |
| P-HP-130 |
1/4" |
17/32" |
30 |
5000 |
49 |
4 |
P-HPL-130 |
5000 |
40 |
| P-HP-135 |
1/4" |
17/32" |
35 |
5000 |
50 |
4 |
P-HPL-135 |
5000 |
40 |
| P-HP-320 |
3/8" |
43/64" |
20 |
4000 |
48 |
4 |
P-HPL-320 |
4000 |
40 |
| P-HP-325 |
3/8" |
43/64" |
25 |
4000 |
50 |
4 |
P-HPL-325 |
4000 |
40 |
| P-HP-330 |
3/8" |
43/64" |
30 |
4000 |
51 |
4 |
P-HPL-330 |
4000 |
40 |
HOSE
INFO: DO NOT EXCEED OUR LISTED HOSE O.D. TO OBTAIN MAXIMUM HOSE
LENGTH.
SIZE
INDEX |
OVERALL REEL
DIMENSIONS |
| WIDTH |
HEIGHT |
LENGTH |
| 1 |
6" |
14-1/2" |
13-3/4" |
| 2 |
6-1/4" |
14-1/2" |
13-3/4" |
| 3 |
6-1/8" |
18-1/4" |
17-1/4" |
| 4 |
7" |
18-1/4" |
17-1/4" | |
