COXREELS' oxy-acetylene, spring-driven hose reels are
auto-rewind reels built using the highest quality, heavy gauge materials.
Each reel is supplied standard with a locking ratchet to hold the desired
length of hose. All models come standard with an 18" inlet hose
assembly.
- Heavy
duty 1/4" plate steel support post and mounting plate
- 1"
oil-lite self-lubricating bearing
- 1"
solid steel center support shaft
- Brass
swivel joint
- Adjustable arm guide (wall, floor, ceiling and pit)
- Cartridge style spring motor
- 4-roller, non-snag hose guide
- 8-position spark-free locking ratchet
 SWIVEL
Body and
spool are made of solid brass. These swivels are designed for
simultaneously conveying two gases. Ported for safety. Double "o"
ring sealed design prevents
leakage. |
|
OXYGEN-ACETYLENE DUAL
HOSE |
Hose supplied on reel is twin-siamese type meeting R.M.A. and
C.G.A. type V.D. grade R specifications. Use of other types of hose is
not recommended.
| DO
NOT USE WITH RATIO PUMP |
| MODEL |
HOSE |
PSI |
APPRX.
SHIP
WT. (lbs) |
SIZE
INDEX
(Chart) |
LESS HOSE |
| I.D. |
O.D. |
FT. |
MODEL |
PSI |
APPRX.
WT. (lbs) |
| P-W-125 |
1/4" |
17/32" |
25 |
200 |
35 |
20 |
P-WL-125 |
200 |
30 |
| P-W-135 |
1/4" |
17/32" |
35 |
200 |
40 |
20 |
P-WL-135 |
200 |
32 |
| P-W-140 |
1/4" |
17/32" |
40 |
200 |
50 |
20 |
P-WL-140 |
200 |
41 |
| SHW-N-150 |
1/4" |
17/32" |
50 |
200 |
69 |
12 |
SHWL-N-150 |
200 |
60 |
| SHW-N-160 |
1/4" |
17/32" |
60 |
200 |
84 |
13 |
SHWL-N-160 |
200 |
73 |
| SHW-N-175 |
1/4" |
17/32" |
75 |
200 |
91 |
13 |
SHWL-N-175 |
200 |
77 |
Hose supplied on reel is twin-siamese type grade "T." Grade "T"
reels and hoses are used for a wide variety of gases, such as mapp gas,
propane gas, natural gas and fuel gases.
| MODEL |
HOSE |
PSI |
APPRX.
SHIP
WT. (lbs) |
SIZE
INDEX
(Chart) |
LESS HOSE |
| I.D. |
O.D. |
FT. |
MODEL |
PSI |
APPRX.
WT. (lbs) |
| P-WT-125 |
1/4" |
17/32" |
25 |
200 |
35 |
20 |
P-WTL-125 |
200 |
30 |
| SHWT-N-150 |
1/4" |
17/32" |
50 |
200 |
69 |
12 |
SHWTL-N-150 |
200 |
60 |
HOSE
INFO: DO NOT EXCEED OUR LISTED HOSE O.D.
TO OBTAIN MAXIMUM USABLE HOSE
LENGTH.
SIZE
INDEX |
OVERALL REEL
DIMENSIONS |
| WIDTH |
HEIGHT |
LENGTH |
| 12 |
10-7/8" |
21" |
19-5/8" |
| 13 |
10-7/8" |
25-1/4" |
23" |
| 20 |
8-1/2" |
18-1/4" |
17-1/4" |
| 30 |
18-7/8" |
18-1/8" |
23-3/4"* |
| 31 |
22-7/8" |
18-1/8" |
23-3/4"* |
| 32 |
28-7/8" |
18-1/8" |
23-3/4"* |
| 33 |
34-7/8" |
18-1/8" |
23-3/4"* | *with
handle |
